Features

-Alignment for Factory Automation Equipments
-Automatic Correction of Shifted Position While Moving
-Optical Alignment for Optical Instrument


Specification

-Detector Size : 9.0x9.0 mm
-DMeasurement Range
  LBPMS-A050 : 50.0 mm-diameter circle centered on the detector center
  (* LBPMS-A100 : 100.0 mm-diameter circle centered on the detector center)
  (* LBPMS-A200 : 200.0 mm-diameter circle centered on the detector center)
-Position Accuracy : 5.0 μm-150.0 μm
-Calibrated Spectral Range
  Power / Position : 400.0 nm - 1550.0 nm
-Max Use Distance (Source to LPSD) : ≤ 40.0 m
-Plug-in Card Configuration : RS232C
-System Requirements
  Chipset : 800-MHz Pentium III or higher running
  OS : Windows 98, Me, NT(except for PCMCIA), 2000, or XP
-Dimensions : 140.0(L)x170.0(W)x240.0(H) mm
-Weight : 3.2 Kg
